Signal Conditioning
comes in most compact Size
Team-Players: xProAnalog8 + xProThermo8
Signal conditioning
convert Analog + Thermos to CAN
Our signal processing units operate consistently on a
24-bit basis, resolving even the smallest signals across
a wide input range.
xproThermo8 converts 8 thermocouple channels into
CAN messages. The resolution is an impressive 0.01 °C.
All channels are galvanically isolated from each other
to avoid problems with GND loops.
xproThermo32 is based on the same sophisticated
technology and can convert 32 channels.
xproAnalog8 converts 8 analog channels to CAN. The
input range is +/-20V and, with 24 bits, has a
resolution better than 1mV. External sensors can be
supplied directly with 5V and 12V.
Parameter settings for e.g. the CAN bus etc. are set via
CAN / USB interface.
All modules can be expanded modularly via the
integrated CAN hub to increase the number of channels.
xproThermo8 / 32
xproAnalog8
precisely measure Thermocouples
24-Bit / 20 Volt Range Analog-2-CAN
•
Multi-channel thermocouple 2-CAN interface
•
Multiple xproThermo modules can be daisy-chained
•
High resolution with up to 1/100 C°
•
Complete galvanic isolation channel-to-channel
•
Status LED for each channel (sensor/cable break)
•
Analog Input Module with 8 channels
•
24-bit resolution and automotive +/- 20 volt range
•
Status LED for each channel
•
Multiple channels can be daisy-chained
•
Same compact design as Thermo8 modules
xproThermo8 / 32
xproAnalog8
•
Analog Input Module with 8 channels
•
24-bit resolution and automotive +/- 20 volt range
•
Status LED for each channel
•
Multiple channels can be daisy-chained
•
Same compact design as Thermo8 modules
built in most compact Size
Team-Player: xProAnalog8 + xProThermo8
precisely measure Thermocouples
24-Bit / 20 Volt Range Analog-2-CAN
Our signal processing units operate throughout on
a 24-bit basis thus capturing even smallest signals
over a large measuring range.
xproThermo8 converts 8 thermocouple channels
into CAN messages. The resolution is an
exceptional 0.01 °C. All channels are galvanically
isolated from each other so that GND loop issues
are avoided. Multiple modules can be daisy-chained
via the integrated CAN hub.
xproThermo32 is based on the same
sophisticated technology as xproThermo8 but can
convert 32 channels instead. Settings of CAN bus
parameters etc. can be configured via a USB.
xProThermo32 is expandable in a modular style.
xproAnalog8 Converts 8 analog channels to CAN.
The input range is +/-20V with a resolution of
better than 1mV at 24 bits.
xproThermo8 - 8 Thermo-K Kanäle
xproThermo32 - 32 Thermo-K Kanäle
xproAnalog8 - 8 Analog-Kanäle +/-20V Range
CAN-Bus Interfacing
Thermo + Analog
•
Multi-channel thermocouple 2-CAN interface
•
Multiple modules can be daisy-chained
•
High resolution with up to 1/100 C°
•
Complete galvanic isolation channel-to-channel
•
Status LED for each channel (sensor/cable break)
Automotive Test Equipment
